• mounted at the tractor´s three point linkage

• highly manouverable and space saving

• Tractor with super creeper gear required

• not appropriate for road transport

• turner with single axle chassis with European hitch

• built in creeper gear

• tractor does not need to have creeper gear

• suitable for multi-site operation

• turner with single axle chassis with European hitch

• tractor does need to have creeper gear

• suitable for multi-site operation

• available in heavy-duty version "s"

Technical Data

FOLD III

TAK III

AK III

AK III-s

throughfeed width [m]

3,00

3,00

3,00

3,30

throughfeed height [m]

1,70

1,70

1,70

1,80

max. windrow height [m]

1,75

1,75

1,75

1,85

total width [m]

5,10

5,10

5,10

5,10

transport height (with side wheel) [m]

4,35

4,35

4,35

4,35

transport height (w.o. side wheel) [m]

3,95

3,95

3,95

4,27

weight[kg]

900

2950

2700

3550

power requirements  min. [HP]

70

70

70

100

power requirements  min. [HP]

90

90

90

140
